Fertilizer Packing Machine Product Information
Fertilizer packaging machine is a packaging machine used for low-dust material lines, used in agricultural fertilizer factories, to help with the packaging aesthetics and safety.
The fertilizer packaging machine has a simple, compact design
Vietnam is an agricultural country so fertilizer issue is the inevitable need of most farmers.
The introduction of An Thanh’s fertilizer packaging machine helps fertilizer manufacturers to solve many problems:
– Fertilizer is better preserved
– Beautiful printed packaging design without fading when put through the packaging stage
– The packaging is easy to open when shipped to the consumer
In addition, our packaging machine is designed with a compact, simple in operation that makes it easy for manufacturers to use.
The machine has a simple, compact structure that also makes cleaning and cleaning easier.
Automatic process for fertilizer packaging machine
An Thanh fertilizer packaging machine is a machine that continuously operates under a multi-function closed process from loading, creating bags, sealing to cutting, date printing without having to stop the machine. Thanks to that, it speeds up production, helping businesses save production time and costs.
High capacity – the thing about fertilizer packaging machine
An Thanh fertilizer packaging machine is assembled from most of high-class imported components, with a capacity of 2 kW / h for an effective productivity of 3-4 times compared to human labor. Specifically, for about 20-30 products / minute depending on the size and weight of the bag.
Specifications of fertilizer packaging machine
Specifications | Material | Origin | Note |
The machine frame is coated in 304 stainless steel and the contact details are made of 304 stainless steel, used in food. | Inox 304 | An Thanh | All components 100% brand new |
Machine parts are machined on CNC machines with high precision. | An Thanh | ||
ABM drives the motor. | Germany | ||
Main motor ABM | Germany | ||
MCP protects the HITACHI machine | Japan | ||
Kasuto Commune Packaging Engine. | Japan | ||
Relay IDEC | Japan | ||
Slip paste system for NTN packaging | Japan | ||
PLC-DELTA data memory | Taiwan | ||
DELTA touch screen The machine parameters are displayed on the touch screen. | Taiwan | ||
Barometer reader sensor Aotoro | Taiwan | ||
|
Brass or inox | An Thanh | |
Door to protect packing machine | |||
Film size: 70mm (changeable) | |||
Bag weight: 17 grams (changeable)
Accuracy ± 1.5% |
|||
Quantitative method: measuring cup | INOX 304 | ||
Packing materials: soluble powder | |||
Speed: 20-40 products / unit depending on product weight. | |||
Electric power: 2 kw / h. | |||
Power supply: 220v / 50hz | |||
Machine size: (D1050 x R850 x C1850) mm | |||
Machine weight: 450kg | |||
Made in machine |
Fertilizer packaging machine – warranty and high-level maintenance
The eyebrows packed from An Thanh are warranted for 12 months from the factory to the customer.
After the warranty period, a periodic maintenance will be activated to monitor the operation of the machines, in order to improve the quality and longevity of the machine.
